Specifications
Manufacturer: MSI
Manufacturer Part Number: X470 GAMING PLUS MAX
Manufacturer Website Address: http://www.msi.com
Brand Name: MSI
Product Model: X470 GAMING PLUS MAX
Product Name: X470 GAMING PLUS MAX Desktop Motherboard
Marketing Information:

Satisfying gamers with what they really need, X470 GAMING PLUS MAX is equipped with Core boost, Turbo M.2, Audio Boost, USB 3.2 Gen2

Product Type: Desktop Motherboard
Processor & Chipset
Chipset Manufacturer: AMD
Total Processor Supported: 1
Processor Socket: Socket AM4
Processor Supported:

• Athlon
• Ryzen

Memory
Number of Memory Slots: 4
Memory Form Factor:

• DIMM
• UDIMM

Maximum Memory Supported: 64 GB
Memory Speed Supported:

• 1866 MHz
• 2133 MHz
• 2400 MHz
• 2667 MHz (O.C.)
• 2800 MHz (O.C.)
• 2933 MHz (O.C.)
• 3000 MHz (O.C.)
• 3066 MHz (O.C.)
• 3200 MHz (O.C.)
• 3466 MHz (O.C.)
• 2667 MHz
• 3733 MHz (O.C.)
• 3866 MHz (O.C.)
• 4000 MHz (O.C.)
• 4133 MHz (O.C.)

Memory Technology: DDR4 SDRAM
I/O Controller
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels:

• 0
• 1
• 10

Video
Onboard Video: CPU Dependent Video
Audio
Audio Channels: 7.1
Network & Communication
Gigabit Ethernet: Yes
I/O Expansions
Number of Total Expansion Slots: 6
Total Number of PCI Express Slots: 6
Number of PCI Express x1 Slots: 3
Number of PCI Express x16 Slots: 3
Interfaces/Ports
Total Number of USB Ports: 8
Number of USB 2.0 Ports: 2
Number of USB 3.2 Ports: 6
S/PDIF: Yes
HDMI: Yes
DVI: Yes
Number of Network (RJ-45) Ports: 1
Onboard Interfaces
Number of SATA Interfaces: 6
Number of M.2 Interfaces: 2
Total Number of Onboard USB Ports: 8
Number of Onboard USB 2.0 Ports: 4
Number of Onboard USB 3.2 Ports: 4
Physical Characteristics
Form Factor: ATX
Width: 305 mm
Depth: 244 mm
Miscellaneous
Country of Origin: China
