GIGABYTE H510M ULTRA DURABLE MICRO ATX INTEL LGA1200 DP HDMI DVI VGA PCIE 4.0 M.2 SATA 2XDDR4

Interfaces Support , Anti-Sulfur Resistor, Smart Fan 6

Key Features:

• Supports 11th and 10th Gen IntelCore Series Processors
• Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
• Ultra-Fast M.2 with PCIe Gen3 X4 & SATA Interface
• GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management
• 4 Display Interfaces Support
• High Quality Audio Capacitors and Audio Noise
• Smart Fan 6 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP
• GIGABYTE APP Center, Simple and Easy Use
• Anti-Sulfur Resistors Design

Specification:

CPU

11th Gen Intel Core i9/i7/i5 processors
10th Gen Intel core i9/i7/i5/i5/Intel Pentium/Intel Celeron processors

Chipset

Intel H510 Express Chipset

Memory

11th Gen Intel Core i9/i7/i5 processors: support for DDr4 3200/3000/2933/2666/2400/2133 MHz memory modules

10th Gen Intel Core i9/i7 processors: support DDR4 2933/2666/2400/2133 MHz memory modules
10th Gen Intel Core i5/i3/Pentium/Celeron processors: support DDR4 2666/2400/2133 MHz memory modules
2 x DDR4 DIMM sockets supporting up to 64GB (32GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support Extreme Memory Profile (XMP) memory modules

Onboard Graphics
Integrated Graphics Processor-Intel HD Graphics support:
1 x D-Sub port, supporing a maxmium resolution of 1920 x 1200 @60Hz
When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only.
1 x DVI-D port, supporing a masmium resolution of 1920×1200@60Hz
The DVI-D port does not support D-Sub connection by adapter.
1 x HDMI ports, supporting a maxmium resolution of 4096x 2160 @30Hz
Support for HDMI 1.4 version and HDCP 2.3
1 x DisplayPort, supporting a maxmium resoultion of 4096 x 2304 @60 Hz
When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only.
Support for up to 2 displays at the same time.

Audio
1. Realtek Audio CODED
2. High Definition Audio
3. 2/4/5.1/7.1-channel
To configure 7.1-channel aution, you need to open the autio software and select Device setting> Playbaack Device to change the default setting first.

LAN
1. Realtek GbE LAN Chip (1 Gbit/100 Mbit)

Expansion Slots
1. 1x PCI Express x16 port, runnning at x 16
The PCI Express x 16 slot conforms to PCI Express 4.0 standard. Supported by 11th Gen process ors only.
2. 2 x PCI Express x 1 slots
The PCI Express x 1 slots confirm to PCI Express 3.0 standard

Storagge Interface
1. 1x M.2 connector ( Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x 4/x 2 SSD support)
The PCIE1_1 slot shares bandwidth with the M.2 connector. When the PCIEX1_1 slot is populated, the M.2 connector suports up to PCIe 3.0 x 2 SSD only.
2. 4 x SATA 6GB/s connectors.

USB
4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 prots available through the internal USB header)
8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB header)

Internal I/O Connectors
1. 2 x 24-pin ATX main power connector
2. 1 x 8 pin ATX 12V power connector
3. 4 x SATA 6 Gb/s connectors
4. 1 x CPU fan header
5. 2 x system fan headers
6. 1 x RGB LED strop header
7. 1 x front panel header
8. 1 x front panel autio header
9. 1 x USB 3.2 Gen 1 header
10. 2 x USB 2.0.1.1 headers
11. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM 2.0 SPI 2.0 module only)
12. 1 x series port header
13. 1 x Clear CMOS jumper

Back Panel Connectors
1. 1 x PS/2 keybpard port
2. 1 x PS/2 mouse port
3. 1 x D-Sub port
4. 1 x DVI-D port
5. 1 x DisplayPorts
6. 1 x HDMI port
7. 2 x USB 3.2 Gen 1 ports
8. 4 x USB 2.0/1.1 ports
9,. 1 x RJ45 port
10. 3 x audio jacks

I/O Controller
1. iTE I/O Controller Chip

1. i7 processors / IntelCore i5 processors
2. 10th Generation IntelCore i9 processors / IntelCore i7 processors / IntelCore i5 processors / IntelCore i3 processors/ IntelPentiumprocessors / IntelCeleronprocessors*
   * Limited to processors with 4 MB IntelSmart Cache, IntelCeleronG5xx5 family.
3. L3 cache varies with CPU
