GIGABYTE AORUS P850W 80 PLUS GOLD MODULAR 135MM 2 BALL BEARING SMART FAN WITH FAN STOP FUNCTION SINGLE 12V RAIL

Features

• Fully Modular Design
• High quality 100% Japanese Capacitors
• 135mm 2 ball bearing smart fan with fan stop function
• 80 PLUS Gold certified: above 90% efficiency at 50% load
• Single +12V rail
• OCP/OTP/OVP/OPP/UVP/SCP protection
• 10 years warranty (Adjusted according to different regions)

• ModelGP-AP850GM
• TypeIntel Form Factor ATX 12V v2.31
• PFCActive PFC (>0.9 typical)
• Input Voltage100-240 Vac (full range)
• Input Current10A
• Input Frequency47-63 Hz
• Output Capacity850W
• Dimension150 x 160 x 86mm
• Fan Type135mm Double ball bearing fan
• 80 PLUSGold
• Efficiency90% at typical load
• MTBF>100,000 hours
• ProtectionOVP/OPP/SCP/UVP/OCP/OTP
• Power Good Signal100ms ~ 150ms
• Hold Up Time> 16m sec at full load (115V)
• Cable TypeFlat, All black
• ConnectorsATX/MB 20+4 Pin x 1 : 650mm
  CPU/EPS 4+4 Pin x 2 : 800mm*1 , 650mm*1
  PCI-e 6+2 Pin x 6 : 750mm*2 , 650mm+150mm*2
  SATA x6 + 4 Pin Peripheral x2 :
  550mm+100mm+100mm+100mm*1
  450mm+100mm+100mm+100mm *1
  4 Pin Peripheral x 3 + 4 pin Floppy x 1 : 450mm+100mm+100mm+100mm*1
  4 Pin Floppy x 1 : 100mm
