Specifications
Manufacturer: D-Link Systems, Inc
Manufacturer Part Number: DAP-1620
Manufacturer Website Address: http://www.dlink.com
Brand Name: D-Link
Product Model: DAP-1620
Product Name: AC1200 Wi-Fi Range Extender
Marketing Information:

The DAP-1620 AC1200 Wi-Fi Range Extender is a portable plug-in repeater that lets you extend an existing wireless network. You can place it anywhere in your home to increase the range of your wireless network. Tiny yet powerful, it supports Wireless AC speeds of up to 1200 Mbps, yet fits in the palm of your hand.

Easy to Set Up, Easy to Use

Set up is simple. There is no need for a computer as you can use the supported QRS Mobile app on your iPhone, iPad, or iPod touch or Android mobile device to set up the DAP-1620 easily. Alternatively, you can use one-touch configuration by pushing the WPS push-button on the DAP-1620 and on the router or AP you want to extend, and the DAP-1620 will automatically configure itself for you. It even includes a built-in setup wizard that lets you configure it wirelessly with a PC or mobile device.

Extend Your Wireless Network

Dual-band technology helps reduce interference from nearby wireless transmitters in the home, and also provides backward compatibility with older wireless devices in your network, allowing you to enjoy a blazing-fast, reliable wireless connection. Alternatively, use the built-in Gigabit Ethernet port and your home’s existing wired Ethernet cabling to extend wireless coverage without worrying about signal strength.

Compact, Convenient Design

This compact device is ideal for use at home or a small office, as it does not take up much space and is ready to use by simply plugging it in. The bright Signal Indicator LED makes finding a suitable location a cinch. Its diminutive wall-plug design easily saves you the hassle of dealing with a power cord. Its sleek, unobtrusive appearance blends easily into the decor of your home or office.

Product Type: Wireless Range Extender
Technical Information
Wireless LAN Standard: IEEE 802.11ac
Frequency Band:

• 2.40 GHz
• 5 GHz

Number of External Antennas: 2
Wireless Transmission Speed: 1.17 Gbit/s
Interfaces/Ports
Ethernet Technology:

• Ethernet
• Fast Ethernet
• Gigabit Ethernet

Number of Network (RJ-45) Ports: 1
PoE (RJ-45) Port: No
VGA: No
HDMI: No
USB: No
Powerline: No
Management Port: No
Physical Characteristics
Form Factor: Wall Mountable
Height: 42 mm
Width: 120 mm
Depth: 59 mm
Weight (Approximate): 139 g
