Specifications
Manufacturer: Eaton Corporation
Manufacturer Part Number: 5PX3000IRT2UAU
Manufacturer Website Address: http://www.eaton.com
Brand Name: Eaton
Product Series: 5PX
Product Model: 5PX3000IRT2UAU
Product Name: 5PX 3000 VA Tower/Rack Mountable UPS
Marketing Information:

The Eaton 5PX Rack/Tower UPS provides line-interactive backup power and scalable runtimes for servers, storage systems, VoIP gear and network equipment. With a next-generation intuitive LCD display, energy consumption metering down to the outlet group level, and up to 99% efficiency, the 5PX is the perfect UPS to protect modern IT equipment.

Product Type: Line-interactive UPS
Technical Information
Plug/Connector Type: IEC 60320 C20
Receptacles:

• 8 x IEC 60320 C13
• 1 x IEC 60320 C19

Power Description
Load Capacity: 3 kVA/2.70 kW
Input Voltage: 220 V AC
Output Voltage:

• 240 V AC
• 208 V AC
• 220 V AC
• 230 V AC

Physical Characteristics
Height: 86.2 mm
Width: 441 mm
Depth: 647 mm
Rack Height: 2U
Form Factor: Rack/Tower
Weight (Approximate): 38.08 kg
Miscellaneous
Package Contents:

• 5PX 3000 VA Tower/Rack Mountable UPS
• Rackmount Kit
• Pedestal Feet
• USB Cable
• Serial Cable
• Screwdriver
• Cable Retention Brackets
• User Guide
• Software Suite CD

Warranty
Limited Warranty: 3 Year
