Specifications
Manufacturer: Alogic
Manufacturer Part Number: UCVGHD-ADP
Manufacturer Website Address: http://www.alogic.co
Brand Name: Alogic
Product Line: Premium
Product Name: 2-in-1 USB-C to HDMI VGA Adapter – Male to 2-Female – Premium Series
Marketing Information:

Connecting a USB-C Source to an HDMI or VGA Display.
The Alogic USB-C to HDMI VGA Adapter is an innovative 2-in-1 solution for connecting a USB-C enabled source such as a Laptop or MacBook to a HDMI or VGA enabled Display. Multiple outputs from the adapter ensures compatibility with almost any Projector, Monitor or Display for travel, or BYOD (Bring Your Own Device) applications at the office. The adapter is compatible with most of the USB-C enabled computers with support for USB-C Display Alt. mode and Thunderbolt 3 ports. The Plug-and-Play adapter has a small foot print and lightweight design perfect for travel, or BYOD (Bring Your Own Device) applications at the office.

The adapter does not support multiple displays at the same time and only one video output is supported on the adapter at a time. If multiple displays are connected at the same time only one of the output will function

• 2-in-1 Video Outputs:HDMI/VGA/DVI from the adapter ensures compatibility with almost any Dsiplay at the office
• Plug and Play – no driver required
• Host powered – no external power required
• Compatible with Thunderbolt 3 ports

Packaged Quantity: 1
Product Type: A/V Adapter
Technical Information
Adapter Type: HDMI/USB/VGA
Connector on First End: Type C Male USB
Connector on Second End:

• 1 x 15-pin HD-15 Female VGA
• 1 x HDMI Female

Maximum Resolution Supported: 3840 x 2160
Features: Plug and Play
Physical Characteristics
Height: 16 mm
Width: 44 mm
Length: 185 mm
